Perfect for challenging environments

TRV Mini

TRV Mini

TRV Mini is perfect for challenging indoor environments with multiple robots and elevator interfaces. The product can support scheduled and on demand deliveries.

The product is fully customizable with latching or lifting mechanism and supports a payload upto 150 pounds.

Specifications

  • Material: Aluminum alloy chassis with ABS casing
  • Dimension: (L x W x H) 26x20x16 in (650x490x390 mm)
  • Payload:150 lbs. (70kg)
  • Payload Attachment: Automatic cart lifting or latching mechanism (Optional)
  • Maximum Speed: 1.2 m/s
  • Navigation: Autonomous routing by LIDAR SLAM technology
  • Safety Scanning LIDAR: Class 1 Safety Rated Laser, PLd safety
    per ISO 13849-1
  • Drive wheels: Differential Drives (BLDC low noise motors), 2
  • wheels Battery: LiFePO4 20-28 VDC, nominal 25.6 VDC 15 hours
    continuous operation
  • Docking Station: 100 to 240 VAC, 50 to 60 Hz

Applications

  • Suitable for any indoor material transportation applications in logistics, automotive and manufacturing industries
  • Multi Story building delivery applications
  • Configurable for system integrator applications

Key Features:

  • Safety Certified key components used (i.e CE/UL Certified LIDARS, Motor Controllers).
  • Premium, reputable key components used (i.e Safety LIDARS are from SICK UK or Equivalent)
  • Drives come with 10 Nm Powerful Passive Brakes for enhanced safety.
  • 10 Years of AMR Product Development Experience incorporated into Mobile Navigation.
  • Our Premium Series houses a “Parallel Safety Monitoring and Controlling Unit” in addition to our standard series’ features, suitable for customers who prefer Enhanced Safety Features
